CHECK OUT OUR PROJECTS

Below we’ve accumulated a few shining examples of the structures we’ve helped create. Take a look at our different structures that are in some iconic locations throughout North America.

Dominion Trails Bridges and Boardwalks, Frisco, Texas

The City of Frisco has embarked on a green space project as an active transportation trail creating the "Dominion Trail" walkway. The 1.26-mile pathway required 3 elevated walkway sections to maintain accessibility throughout the topography. The intent was to utilize light weight Fiber Reinforced Polymer (FRP) to allow light touch to the environment and reducing sizes of cranes required. FRP gives superior durability performance giving the City of Frisco a long-life asset.



Bridges - 9 Bridges Totaling 500 Linear Feet

  • Trail A: Four truss bridges (40ft.- 70ft. -60ft.) spanning 170 ft. and a 40 ft. with 100ft. boardwalk
  • Trail B: Three truss bridges (40ft.-70ft.-40ft.) spanning 150ft.
  • Trail C: Two truss bridges (100ft. - 40ft.) spanning 140 ft. and two boardwalks 135 ft. and 35 ft.

Pfeiffer Falls Pedestrian Trail Bridge, Big Sur, California

•70 ft. (21.3 m) x 7 ft. (2.1 m) pedestrian trail bridge

•Innovative installation methods due to the lack of vehicular access to the bridge site and a timber decking option for aesthetics

•The truss was delivered to a staging area about one mile from the site. Wagners staff worked closely with state parks construction crews to transport, splice, and set the truss using a highline cable system in the redwood trees.

Mersey River Pedestrian Bridge, Kejimikujik National Park, Nova Scotia, Canada

  • 100 ft. long (30.5 m) x 6 ft. wide (1.8 m) single-span pedestrian bridge
  • Bridge erected in logistically challenging area using highline system
  • Canadian Broadcasting Corporation (CBC) News video for Kejimkujik National Park Video: https://www.cbc.ca/player/play/1994768451657

Pine Oaks Wetland Boardwalk, Ocala, Florida

• 1500 ft. (457.2 m) boardwalk with 2 viewing platforms

•The City of Ocala chose Wagners as their designer and supplier of this resilient, long-lived community asset that is highly corrosion resistant and UV resistant

•Time Lapse video from start to finish                https://www.youtube.com/watch?reload=9&time_continue=4&v=CYF6eQQffcI&feature=emb_title

Lake Nasworthy Fishing Pier, San Angelo, Texas

  • Design and supply of 220 ft. (67.1 m) of an all FRP pier and shade structure in San Angelo, Texas.

New Oregon road Bridge, Erie County, New York

  • Erie County Public Works Department had completed significant maintenance on their bridges due to corrosion of the superstructure from de-icing salt
  • Wagners designed and manufactured prefabricated bridges panels constructed using a hybrid of FRP superstructure and concrete deck panels
  • The bridges were installed using minimal equipment and bridge panels installed in 31 days
  • Wagners CFT Bridges have been in place for 16 years with no maintenance required
  • The North Collins bridge were designed, manufactured, and installed under the FHWA Innovative Bridge Replacement and Construction Program

Castle Rock State Park Pedestrian Trail Bridge, Santa Cruz, California

  • 26 ft. (7.9 m) x 4 ft. (1.2 m) girder bridge with stacked 4x10 RHS mudsills
  • The parts and pieces were hiked in 2 miles
  • The mudsills provide anchor point for our girder bridges

Brittany Bay Park Viewing Platform, Miami Beach, Florida

•8 ft. (2.44 m) wide in front x 25 ft. (7.62 m) wide in the back x 30 ft. (9.14 m) long
•Miami Beach shoreline

Ernie Miller Nature Center Pedestrian Bridge, Olathe, Kansas

  • 80 ft. (24.4 m) long x 10 ft. (3 m) wide Pedestrian Bridge
  • H-10 vehicular loading

Tribble Mill Park Pedestrian Bridge, Lawrenceville, Georgia

  • 30 ft. (9.1 m) x 6 ft. (1.8 m) pedestrian bridge
  • Lightweight riveted truss bridge

Hagar Pedestrian Bridge, Boxborough, Massachusetts

• 30 ft. (9.1 m) x 5 ft. (1.5 m) Pedestrian Bridge
